HYBRID WATERPROOF ELECTRIC MOTOR
HYBRID WATERPROOF ELECTRIC MOTOR
하이브리드 방수형 전동기
The increase in greenhouse gases due to global warming caused a rise in global temperature and a rise in seawater temperature, and as a result, many glaciers, typhoons, and storms, heavy rain occurred, and flooding accidents occurred in areas or facilities where drainage facilities were not satisfactory.
Among flooding facilities, when a water purification plant is flooded, large-scale flooding accidents such as houses and roads due to outages of domestic water, industrial water outages, and drainage facilities are not in operation, and the social and economic losses are enormous.
The hybrid waterproof motor developed by SN Co., Ltd. is manufactured with an IP68 structure, and even if the outside of the motor is flooded, there is no water immersion to the inside, and even if the inside of the motor is flooded, it can be operated immediately after draining.
| Rotor structure | Squirrel cage |
|---|---|
| Voltage | 3.3KV, 6.6KV, 11KV |
| Output | 100~4000Kw |
| Frame | 315~630Fr |
Features
- Hybrid waterproof frame with IP68 structure
- Excellent insulation during motor immersion through winding with Nano Epoxy Varnish
- Waterproof structure with special seals applied to the inside and outside of the bearing
- The realization of high efficiency by applying a high-efficiency core and applying a high-performance cooling fan
- Application of cool-vented housing Low noise
